Easy Wheel is a multi-task Phased Array scanning device for effortless heavy duty inspections
Tailored PAUT wheel solution for the scanning of large areas. It allows to rapidly switch probes, ensures ease of deployment and use, offers enhanced ergonomics for the operator, permits access to tight spaces, etc.
Technical Specifications
- Device dimensions: 17 x 13,5 x 16 cm
- Device weight: < 1,5 kg
- Complete maintenance kit
- Laser guiding & encoding systems
- Miscellaneous extras (water, Glycol, pump, etc.)
- Heavy duty transport case (57 x 34 x 21 cm, 8 kg)
- One body, several probe configurations
- Rapid probe swap tooling
- Effortless filling and purge system
- Air chamber entrapment device
- Unique handle design
- Compatible with Smart U32 and other PAUT instruments
Linear arrays characteristics:
- Frequency: from 1MHz up to 10MHz
- Number of elements: from 32 up to 128
Pitch by number of elements:
- 32 elements: 1.6mm
- 64 elements: 0.8mm
- 128 elements: 0.4mm
