Easy Wheel

EasyWheel front left
EasyWheel front view
EasyWheel right view
EasyWheel left view
EasyWheel back view
EasyWheel top view
Connector for air filling and release
adjustable 3-point roller system
EasyWheel with unmounted laser element

Easy Wheel is a multi-task Phased Array scanning device for effortless heavy duty inspections

Tailored PAUT wheel solution for the scanning of large areas. It allows to rapidly switch probes, ensures ease of deployment and use, offers enhanced ergonomics for the operator, permits access to tight spaces, etc.

Technical Specifications

  • Device dimensions: 17 x 13,5 x 16 cm
  • Device weight: < 1,5 kg
  • Complete maintenance kit
  • Laser guiding & encoding systems
  • Miscellaneous extras (water, Glycol, pump, etc.)
  • Heavy duty transport case (57 x 34 x 21 cm, 8 kg)
  • One body, several probe configurations
  • Rapid probe swap tooling
  • Effortless filling and purge system
  • Air chamber entrapment device
  • Unique handle design
  • Compatible with Smart U32 and other PAUT instruments

Linear arrays characteristics:

  • Frequency: from 1MHz up to 10MHz
  • Number of elements: from 32 up to 128

Pitch by number of elements:

  • 32 elements: 1.6mm
  • 64 elements: 0.8mm
  • 128 elements: 0.4mm
