[Press Release] Test releases customizable SDK of its multi-methods acquisition systems

Toulouse, December 1st 2020


Testia, an Airbus company, keeps supporting innovation & research for industrial applications through a customizable SDK of its multi-methods acquisition systems

Testia, an Airbus Company, stays true to its values by developing technology and solutions that stimulate innovation for the industry as a whole. Its current acquisition systems portfolio, comprised by the multi-method UE1 Box and phased array U32 Box, are now open to those who need to exploit their flexibility at maximum to meet multiple technical specifications and accomplish different inspection goals, all within the same device.

The current economic context is pushing industrial players and R&D centers to concentrate their efforts on improving the efficiency of all their activities, maintaining value delivery and thus improving their competitiveness. The challenge for them is to find practical, cost-effective and reliable platforms to train their personnel, conduct experiments, perform tests and integrate the outcomes into industrial operation.

The acquisition platforms

The Box concept is conceived to deliver hardware and software on embeddable units. This architecture allows operators to define best suitable NDT inspection methods for their operations whether it is a desk job, a remote task or a large machine.

The UE1 Box device allows to perform ultrasonic testing (UT) and eddy current testing (ET) including bore holes with rotary probes and/or resonance data acquisition all-in-one. It is fully suitable to test any type of material for defect detection, material characterization, thickness assessment, etc.

The U32 Box device is dedicated to phased array ultrasonic data acquisition including also conventional UT. With its 32 elements, it is fully suitable for ultrasonic inspection automation of aerospace parts as well as for other applications.

UE1Box front view
UE1 Box
The 32Box front and back
U32 Box

No more black boxes – now boxes are transparent

In response to challenges nowadays, Testia has centered its efforts into delivering smart and scalable solutions; this means that users of this equipment now can shift from just operating the device to interacting directly with it.

Thanks to the dedicated SDK packages, users can directly drive the associated software to give precise instructions to the box and manipulate its functions in a very flexible way. This capability allows users to fully exploit the equipment’s features at their maximum. The applications for this technology extend exponentially, because operators can use the device from a traditional NDT acquisition system for specialized tests in research centers or for training purposes up to a dedicated device for production line applications.

For instance, this solution is already being used in many of Testia’s customers’ sites for in-line assessment of elementary parts and/or finished products and on new manufacturing process lines. But also, in one of our clients’ on-going collaborative R&D project for automatized combined NDT inspections methods of metallic parts.

Thinking, developing, testing and rolling-out have never been that simple

The SDKs provide a set of functions that allow to dynamically control Testia’s Box via their current software. They are categorized and organized per type such as: Initiators, Getters and Setters to ease their adoption by the developer. The tree architecture permits to quickly picture and access all the functions available in the library in order to:

  • design your own acquisition software,
  • quickly implement your workflow and
  • obtain instantaneous results.

Coupled with the detailed documentation, examples and support, it has never been easier to create your software.

From desk to production line with UE1 Box & U32 Box
